LED Street Light 49 — technical sheet

ARTIC TEC

GARDEN LIGHT 120W/60W/30W

Elegant design of appearance
Smooth die-cast aluminum housing to prevent dust and snow build-up
IP65 and IK07
Galvanized iron post
100lm/w and 3 years warranty
Area application: Park and squares, Private garden, courtyard corridor, Commercial district street, Tourist attractions.
Install: Post mounted — see fixture heights.

Highlight

Elegant design of appearance

Item No.	FJ-GL01-120W	FJ-GL02-60W	FJ-GL03-30W
Power	120W	60W	30W
Lumen Efficiency	100lm/w	100lm/w	100lm/w
Lumen	12000lm	6000lm	3000lm
Product Size	420×450 mm	450×550 mm	350×350 mm
Post Size	1300×4200 mm	450×4550 mm	350×4350 mm
Power Factor (PF)	>0.9	>0.9	>0.9
Working Voltage	175-245V, 50/60Hz	175-245V, 50/60Hz	175-245V, 50/60Hz
CCT	3000k/4000k/6000k optional	3000k/4000k/6000k optional	3000k/4000k/6000k optional
CRI	80	80	80
Angle	120°	120°	300°
IP Rating	IP65	IP65	IP65
IK Rating	IK07	IK07	IK07
Body Material	Aluminum + tempered glass, PC and iron	Aluminum + tempered glass, PC and iron	Aluminum + tempered glass, PC and iron
Chips	SANAN	SANAN	SANAN
Driver Brand	Artic Tec	Artic Tec	Artic Tec
Working Temperature	-20°C ~ +55°C	-20°C ~ +55°C	-20°C ~ +55°C
Working Humidity	10%-90% RH	10%-90% RH	10%-90% RH
Lifespan	25,000hrs	25,000hrs	25,000hrs
Warranty	3 years	3 years	3 years
Housing Color	Black and grey	Black and grey	Black and grey
Reasonable Tolerance	Watt: ±10%, CCT: ±500K, Lumen efficiency: ±5%	Watt: ±10%, CCT: ±500K, Lumen efficiency: ±5%	Watt: ±10%, CCT: ±500K, Lumen efficiency: ±5%

Fixture information · AxBxC (mm)

Package information · AxBxC (mm) · PCS/carton
